管道外壁自動噴砂機
◆使用面積 Applicable scope
管(guan)類(lei)工件(jian)產品,如:槽鋼(gang)管(guan)、槽鋼(gang)、拉杠、螺旋軸、玄幻(huan)柱體、圓罐類(lei)、柱體型零件(jian);使用(yong)雙槍(可按要(yao)多槍)及颶風式抑塵器(qi)和(he)光電公司(si)感(gan)測器(qi)功能鍵,增(zeng)加了工作的(de)效(xiao)率(lv)及極大的(de)的(de)縮減了搶修率(lv)。 (此cpu型號需預(yu)約)
The kind of pipe workpieces, such as: steel pipe, round steel, bars, screw, large cylindrical, cylinder, round the plant; Adopt double gun (according to demand more gun) and new filter and light electricity function, improve the production efficiency and reduce the maintenance rate. (the model need to customize)
◆核心技術系統參數 Main technical parameters
|
機器人應用 Model |
STR-1500管道外壁自動噴砂機 |
STR-1800輥傳動雙槍自動噴砂機 |
|
任務艙寸尺 Working class size(mm) |
1000×900×900 |
1800×900×1000 |
|
主機厚度 Complete machine size(mm) |
1200×900×2900 |
1900×900×2900 |
|
解壓縮暖空氣源 Compressed air source |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
|
電源模塊 Power |
220v 50Hz |
220v 50Hz |
|
直流變頻交流電動機調速器器 Governor |
250W×2 |
250W×2 |
|
提取器馬達 Separator motor |
380v 50Hz 4kw |
220v 50Hz 1.1kw |
|
拆分器功率 Air separator |
35m3/min |
35m3/min |
|
機總重 Machine weight |
900kg |
900kg |
