◆好產品特色 Product features(請往(wang)前閱讀(du)多大量的例子照片集(ji)供分類)
噴砂機主要用于電鍍、噴漆、噴涂等所有被覆蓋加工前噴砂處理;舊樣翻新清洗;金屬制品及塑膠、水晶、玻璃等表面痕跡消除,啞光霧面處理,使產品表面提升檔次;機加工零件微小毛刺去除;增加金屬件表面硬度,消除應力如彈簧、機加工刀具等;金屬制品及非金屬制品表面刻蝕圖案、文字及防滑處理,如大理石、印章、手柄防滑等。本機應用范圍:適用于大量中小型一般工件及高硬度工件的快速噴砂。如發動機配件、閥門、熱處理工件等。該機型設計新穎,結構科學合理,操作方便,加工性能優越;噴砂速度快,撞擊點深。
Features: Sandblasting machine is mainly used in electroplating, paint, coating area to-be-covered before piating; Old way of refurbished cleaning; Metal products and plastic, crystal, glass surface trace eliminate scattered, dumb, surface process to enhance the grade of the product's surface; Machining parts tiny burrs purify; Increase the metal surface hardness, eliminate stress such as spring, mechanical cutters, etc.; Metal and non-metai products surface etching pattern, writing and prevent slippery processing, such as marble, seals, and handle prevent slippery, etc. The machine is applied the range: applicable to small and medium-sized general of workpiece and high hardness workpieces quickly sandblasting. Such as engine fittings, valves, heat treatment workpiece, etc. This machine has novel, scientific design and reasonable structure, convenient operation, processing superior performance; Gush arenaceous speed, the impact point at deep.
◆可用于範圍 Applicable scope
電子器材五金機械(xie)類(lei),ABS塑料制品,亞(ya)克力板,模具設備。中重型鏜(tang)孔產(chan)品、型式件、聚酯樹(shu)脂等鏜(tang)孔產(chan)品或流(liu)程品噴(pen)砂。
Applicable scope: electronic hardware class, ABS plastic, acrylic, resin, workpiece or handicraft sandblasting
◆具體技術工藝型號規格 Main technical parameters供規范(fan)大概與(yu)業務員保持聯系
|
設備款型 Model |
STR-9070 |
STR-9080 |
STR-1010 |
STR-1212 |
|
工做艙厚度 Internal size(mm) |
900×700×790 |
900×800×700 |
1000×1000×670 |
1180×1180×980 |
|
空機(ji)尺碼 Complete machine size(mm) |
900×700×1780 |
950×850×1720 |
1000×1000×2100 |
1200×1200×2580 |
|
煙氣凈化(hua)箱(xiang)尺寸圖 Dedust box sizes(mm) |
600×600×1680 |
600×600×1680 |
600×600×1680 |
800×800×1780 |
|
電源開關 Power |
220V 50Hz |
220V 50Hz |
220V 50Hz |
220V 50Hz |
|
機燈(deng)光燈(deng) Machine floodlight |
220V 20W 節能減排燈(deng) |
220V 20W 環(huan)保燈 |
220V 20W 節(jie)能技術燈 |
220V 20W 工業節能燈(deng)管(guan) |
|
分離(li)處理器無刷電(dian)機 Separator motor |
220V 50Hz 0.55-3KW |
220V 50Hz 0.55 |
220V 50Hz 0.55-3KW |
220V 50Hz 0.55-3KW |
|
提取器新風量 Separator air volume |
8.5m3/min |
8.5m3/min |
8.5m3/min |
8.5m3/min |
|
文件壓(ya)縮氣源 Compressed air source |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
|
POS機容量(liang) Weight |
380kg |
380kg |
400kg |
380kg |
